Cache implementation in Node.js

I know: there are several good modules in npm world but sometimes we don’t have enough flexibility in terms of customizations. In my case I invested more time trying to tweak an existing module than develop my own

Cache data can be as easy as a collection in memory that holds our most used records for the whole life cycle of our web app. For sure, that approach does not scale if we our web app receives several hits or if we have a huge amount of records to load in memory.

There are cache at different levels such as web or persistence. This implementation will cache data at persistence layer.

Take this implementation as a starting point. Probably won’t be the most optimized solution to resolve your problem. There’s not magic, you will have to spend some time until you get good results in terms of performance

Among others reasons you will cache because:

  • Reduce response time
  • Reduce stress of your database
  • Save money: less CPU, less memory, less instances, etc.

Let’s code a simple solution as a first attempt.

If you want to go straight to the source code, go ahead https://github.com/andrescanavesi/node-cache

I will use Express js framework and Node.js 12

$ express --no-view --git node-cache

   create : node-cache/
   create : node-cache/public/
   create : node-cache/public/javascripts/
   create : node-cache/public/images/
   create : node-cache/public/stylesheets/
   create : node-cache/public/stylesheets/style.css
   create : node-cache/routes/
   create : node-cache/routes/index.js
   create : node-cache/routes/users.js
   create : node-cache/public/index.html
   create : node-cache/.gitignore
   create : node-cache/app.js
   create : node-cache/package.json
   create : node-cache/bin/
   create : node-cache/bin/www

   change directory:
     $ cd node-cache

   install dependencies:
     $ npm install

   run the app:
     $ DEBUG=node-cache:* npm start
$ cd node-cache
$ npm install

Open the file app.js and remove the line

app.use(express.static(path.join(__dirname, 'public')));

Install nodemon to auto-restart our web app once we introduce changes

npm install nodemon --save

Open the file package.json and modify the line

"start": "nodemon ./bin/www"

Before was:

"start": "node ./bin/www"

Install the tools needed for tests

npm install mocha --save-dev
npm install chai --save-dev
npm install chai-http --save-dev
npm install nyc --save-dev
npm install mochawesome --save-dev
npm install randomstring --save-dev

Maybe you already know mocha and chai but we also installed some extra tools:

  • nyc: code coverage.
  • mochawesome: an awesome html report with our test results.
  • randomstring: to generate some random data

After installing them we need to make some configurations:

  • Create a folder called tests in the root of our project.
  • In our .gitignore file add reports folder to be ignored tests/reports/
  • Open package.json file and add a test command at scripts
 "scripts": {
        "start": "nodemon ./bin/www",
        "test": "NODE_ENV=test nyc --check-coverage --lines 75 --per-file --reporter=html --report-dir=./tests/reports/coverage mocha tests/test_*.js --recursive --reporter mochawesome --reporter-options reportDir=./tests/reports/mochawesome --exit"
    },

Create a file tests/test_cache.js with some basic stuff in order to test configuration

const app = require("../app");
const chai = require("chai");
const chaiHttp = require("chai-http");
const assert = chai.assert;
const expect = chai.expect;
const {Cache} = require("../utils/Cache");

// Configure chai
chai.use(chaiHttp);
chai.should();

describe("Test Cache", function() {
    this.timeout(10 * 1000); //10 seconds

    it("should cache", async () => {
        //
    });
});

Execute tests to make sure everything is configured

npm test

The output will be something like this

  Test Cache
    ✓ should cache


  1 passing (6ms)

[mochawesome] Report JSON saved to /Users/andrescanavesi/Documents/GitHub/node-cache/tests/reports/mochawesome/mochawesome.json

[mochawesome] Report HTML saved to /Users/andrescanavesi/Documents/GitHub/node-cache/tests/reports/mochawesome/mochawesome.html

ERROR: Coverage for lines (29.41%) does not meet threshold (75%) for /Users/andrescanavesi/Documents/GitHub/node-cache/routes/index.js
ERROR: Coverage for lines (50%) does not meet threshold (75%) for /Users/andrescanavesi/Documents/GitHub/node-cache/daos/dao_users.js
ERROR: Coverage for lines (28.57%) does not meet threshold (75%) for /Users/andrescanavesi/Documents/GitHub/node-cache/utils/Cache.js
npm ERR! Test failed.  See above for more details.

Tests failed and that’s ok because we did not implement any test. Let’s implement it later.

Cache implementation

Create a utils folder and our Cache.js file

/**
 * @param name a name to identify this cache, example "find all users cache"
 * @param duration cache duration in millis
 * @param size max quantity of elements to cache. After that the cache will remove the oldest element
 * @param func the function to execute (our heavy operation)
 */
module.exports.Cache = function(name, duration, size, func) {
    if (!name) {
        throw Error("name cannot be empty");
    }
    if (!duration) {
        throw Error("duration cannot be empty");
    }
    if (isNaN(duration)) {
        throw Error("duration is not a number");
    }
    if (duration < 0) {
        throw Error("duration must be positive");
    }
    if (!size) {
        throw Error("size cannot be empty");
    }
    if (isNaN(size)) {
        throw Error("size is not a number");
    }
    if (size < 0) {
        throw Error("size must be positive");
    }
    if (!func) {
        throw Error("func cannot be empty");
    }
    if (typeof func !== "function") {
        throw Error("func must be a function");
    }

    this.name = name;
    this.duration = duration;
    this.size = size;
    this.func = func;
    this.cacheCalls = 0;
    this.dataCalls = 0;
    /**
     * Millis of the lates cache clean up
     */
    this.latestCleanUp = Date.now();
    /**
     * A collection to keep our promises with the cached data.
     * key: a primitive or an object to identify our cached object
     * value: {created_at: <a date>, promise: <the promise>}
     */
    this.promisesMap = new Map();
};

/**
 * @returns
 */
this.Cache.prototype.getStats = function(showContent) {
    const stats = {
        name: this.name,
        max_size: this.size,
        current_size: this.promisesMap.size,
        duration_in_seconds: this.duration / 1000,
        cache_calls: this.cacheCalls,
        data_calls: this.dataCalls,
        total_calls: this.cacheCalls + this.dataCalls,
        latest_clean_up: new Date(this.latestCleanUp),
    };
    let hitsPercentage = 0;
    if (stats.total_calls > 0) {
        hitsPercentage = Math.round((this.cacheCalls * 100) / stats.total_calls);
    }
    stats.hits_percentage = hitsPercentage;
    if (showContent) {
        stats.content = [];
        for (let [key, value] of this.promisesMap) {
            stats.content.push({key: key, created_at: new Date(value.created_at)});
        }
    }
    return stats;
};

/**
 * @param {*} key
 */
this.Cache.prototype.getData = function(key) {
    if (this.promisesMap.has(key)) {
        console.info(`[${this.name}] Returning cache for the key: ${key}`);
        /*
         * We have to see if our cached objects did not expire.
         * If expired we have to get freshed data
         */
        if (this.isObjectExpired(key)) {
            this.dataCalls++;
            return this.getFreshedData(key);
        } else {
            this.cacheCalls++;
            return this.promisesMap.get(key).promise;
        }
    } else {
        this.dataCalls++;
        return this.getFreshedData(key);
    }
};

/**
 *
 * @param {*} key
 * @returns a promise with the execution result of our cache function (func attribute)
 */
this.Cache.prototype.getFreshedData = function(key) {
    console.info(`[${this.name}] Processing data for the key: ${key}`);
    const promise = new Promise((resolve, reject) => {
        try {
            resolve(this.func(key));
        } catch (error) {
            reject(error);
        }
    });
    const cacheElem = {
        created_at: Date.now(),
        promise: promise,
    };

    this.cleanUp();
    this.promisesMap.set(key, cacheElem);
    return promise;
};

/**
 * @param {*} key
 */
this.Cache.prototype.isObjectExpired = function(key) {
    if (!this.promisesMap.has(key)) {
        return false;
    } else {
        const object = this.promisesMap.get(key);
        const diff = Date.now() - object.created_at;
        return diff > this.duration;
    }
};
/**
 * Removes the expired objects and the oldest if the cache is full
 */
this.Cache.prototype.cleanUp = async function() {
    /**
     * We have to see if we have enough space
     */
    if (this.promisesMap.size >= this.size || Date.now() - this.latestCleanUp > this.duration) {
        let oldest = Date.now();
        let oldestKey = null;
        //iterate the map to remove the expired objects and calculate the oldest objects to
        //be removed in case the cache is full after removing expired objects
        for (let [key, value] of this.promisesMap) {
            if (this.isObjectExpired(key)) {
                console.info(`the key ${key} is expired and will be deleted form the cache`);
                this.promisesMap.delete(key);
            } else if (value.created_at < oldest) {
                oldest = value.created_at;
                oldestKey = key;
            }
        }

        //if after this clean up our cache is still full we delete the oldest
        if (this.promisesMap.size >= this.size && oldestKey !== null) {
            console.info(`the oldest element with the key ${oldestKey} in the cache was deleted`);
            this.promisesMap.delete(oldestKey);
        }
    } else {
        console.info("[cleanUp] cache will not be cleaned up this time");
    }
};

/**
 * Resets all the cache.
 * Useful when we update several values in our data source
 */
this.Cache.prototype.reset = function() {
    this.promisesMap = new Map();
    this.latestCleanUp = Date.now();
    this.cacheCalls = 0;
    this.dataCalls = 0;
};

Let’s see how we use our cache file. Let’s create a daos folder and dao_users.js file

const {Cache} = require("../utils/Cache");

//our datasource. In real life this connection will be a database
const allUsers = [];
/**
 * Creates some users for our allUsers collection
 */
module.exports.seed = function() {
    for (let i = 0; i < 10; i++) {
        allUsers.push({id: i, name: "user" + i});
    }
};

const cacheAllUsers = new Cache("all users", 1000 * 5, 20, key => {
    return "Im cache all users func with the key: " + key;
});

const cacheUserById = new Cache("user by id", 1000 * 5, 30, userId => {
    let i = 0;
    do {
        if (allUsers[i].id === userId) {
            return allUsers[i];
        }
        i++;
    } while (i < allUsers.length);

    return null;
});

/**
 *
 */
module.exports.findAll = async function() {
    //console.info(cacheAllUsers.getStats());
    return cacheAllUsers.getData(1);
};

/**
 * @param {number} id
 */
module.exports.findById = async function(id) {
    return cacheUserById.getData(id);
};

/**
 * @returns an array containing all caches stats
 */
module.exports.getCacheStats = function(showContent) {
    return [cacheUserById.getStats(showContent), cacheAllUsers.getStats(showContent)];
};

Our routes/index.js file

var express = require("express");
var router = express.Router();

const daoUsers = require("../daos/dao_users");

router.get("/", async function(req, res, next) {
    try {
        daoUsers.seed();
        await daoUsers.findAll();
        await daoUsers.findAll();
        await daoUsers.findAll();
        await daoUsers.findById(1);
        await daoUsers.findById(2);
        await daoUsers.findById(1);
        await daoUsers.findById(2);
        await daoUsers.findById(2);
        await daoUsers.findById(444);
        await daoUsers.findById(444);
        await daoUsers.findById(444);
        const cacheStats = daoUsers.getCacheStats(true);
        res.json(cacheStats);
    } catch (error) {
        next(error);
    }
});

module.exports = router;

Let’s resume our tests cases.

The test_cache.js file

const chai = require("chai");
const assert = chai.assert;
var randomstring = require("randomstring");
const {Cache} = require("../utils/Cache");

describe("Test Cache", function() {
    this.timeout(10 * 1000); //10 seconds

    /**
     * Dummy function to use in our cache when we eant to test others parts of our cache class
     * so no matter which function we use
     */
    const dummyFunc = key => {
        return "test";
    };

    describe("Test Cache constructor", function() {
        it("should not allow cache creation without name", async () => {
            try {
                new Cache(null, 1, 1, dummyFunc);
                assert.fail("Should not create a cache without name");
            } catch (e) {
                assert.isNotNull(e);
                assert.equal(e.message, "name cannot be empty");
            }
        });
        it("should not allow cache creation without duration", async () => {
            try {
                new Cache("abc", null, 1, dummyFunc);
                assert.fail("Should not create a cache without duration");
            } catch (e) {
                assert.isNotNull(e);
                assert.equal(e.message, "duration cannot be empty");
            }
        });
        it("should not allow cache creation without size", async () => {
            try {
                new Cache("abc", 1, null, dummyFunc);
                assert.fail("Should not create a cache without size");
            } catch (e) {
                assert.isNotNull(e);
                assert.equal(e.message, "size cannot be empty");
            }
        });
        it("should not allow cache creation without a function", async () => {
            try {
                new Cache("abc", 1, 1, null);
                assert.fail("Should not create a cache without a function");
            } catch (e) {
                assert.isNotNull(e);
                assert.equal(e.message, "func cannot be empty");
            }
        });
    });

    describe("Test getStats", function() {
        it("should validate stats", async () => {
            const cacheName = randomstring.generate(8);
            const cache = new Cache(cacheName, 1, 1, dummyFunc);
            const stats = cache.getStats();
            assert.isNotNull(stats);
            assert.equal(stats.name, cacheName);
        });
    });

    describe("Test getData", function() {
        it("should validate getData", async () => {
            const cacheName = randomstring.generate(8);
            const cache = new Cache(cacheName, 1, 1, dummyFunc);
            let data = await cache.getData(1);
            assert.isNotNull(data);
            data = cache.getData(1);
            assert.isNotNull(data);
        });
    });

    describe("Test cleanUp", function() {
        it("should clean up", async () => {
            const cacheName = randomstring.generate(8);
            const cache = new Cache(cacheName, 1, 1, dummyFunc);
            await cache.cleanUp();
        });
    });

    describe("Test isObjectExpired", function() {
        it("should reset", async () => {
            const cacheName = randomstring.generate(8);
            const cache = new Cache(cacheName, 1, 1, dummyFunc);
            await cache.isObjectExpired(1);

            await cache.isObjectExpired(undefined);
            await cache.isObjectExpired(null);
            await cache.isObjectExpired("");
            await cache.isObjectExpired(" ");
        });
    });

    describe("Test getFreshedData", function() {
        it("should getFreshedData", async () => {
            const cacheName = randomstring.generate(8);
            const cache = new Cache(cacheName, 1, 1, dummyFunc);
            await cache.getFreshedData(1);
        });
    });

    describe("Test reset", function() {
        it("should reset", async () => {
            const cacheName = randomstring.generate(8);
            const cache = new Cache(cacheName, 1, 1, dummyFunc);
            await cache.reset();
        });
    });
});

The test_route_index.js file

const app = require("../app");
const chai = require("chai");
const chaiHttp = require("chai-http");
const assert = chai.assert;
const expect = chai.expect;

// Configure chai
chai.use(chaiHttp);
chai.should();

function assertNotError(err, res) {
    if (err) {
        log.error(err.message);
        assert.fail(err);
    }
}

describe("Test index route", function() {
    this.timeout(10 * 1000); //10 seconds

    it("should get index", function(done) {
        chai.request(app)
            .get("/")
            .end(function(err, res) {
                assertNotError(err, res);
                expect(res).to.have.status(200);
                done();
            });
    });
});

Full source code: https://github.com/andrescanavesi/node-cache

Photo by Marc-Olivier Jodoin on Unsplash

Leave a Reply

Fill in your details below or click an icon to log in:

WordPress.com Logo

You are commenting using your WordPress.com account. Log Out /  Change )

Google photo

You are commenting using your Google account. Log Out /  Change )

Twitter picture

You are commenting using your Twitter account. Log Out /  Change )

Facebook photo

You are commenting using your Facebook account. Log Out /  Change )

Connecting to %s
